(5) Start Options
Setting screen of Start Options
Boot settings. The descriptions are shown in below figure.
Item Description
Keyboard NumLock State Select ON/OFF of keyboard numlock at boot.
Keyboard Speed Set typematic rate of keyboard.
Disketteless Operation By selecting ENABLE, configuration error message will not
be displayed at boot whichever FDD is connected or not.
Monitorless Operation Only DISABLE is permitted.
Keyboardless Operation By selecting ENABLE, configuration error message will not
be displayed at boot whichever keyboard is connected or not.
First Startup Device
Second Startup Device
Third Startup Device
Fourth Startup Device
Define order of boot.
Power On Self Test By selecting QUICK, memory test will not run at boot.
Only ENHANCED is permitted.
Virus Detection By selecting ENABLE, changing coot sector code causes
warning message at next boot.
＊
2
Sure Test Only DISABLE is permitted.
*2: Warning message will be displayed at next boot after changing parameter to ENABLE.
IBM SurePath Setup – (C) Copyright IBM Corporation 1994
Start Options
keyboard NumLock State
keyboard Speed
Disketteless Operation
Monitorless Operation
Automatic Configuration
PCMCIA ATA Card
First Startup Device
Second Startup Device
Third Startup Device
Fourth Startup Device
Power On Self Test
Virus Detection
[ On ]
[ Fast ]
[ Disabled ]
[ Disabled ]
[ Disabled ]
[ Enabled ]
[ Diskette Drive 0 ]
[ Hard Disk 0 ]
[ Disabled ]
[ Disabled ]
[ Enhanced ]
[ Disabled ]
<F1> Help < >< > Move < > Next Value <F9> Restore Setting
<Esc> Exit < > Previous Value <F10> Default Settin
g
02 99.07.29 Added this page.
