(7) Power Management
Setting Screen of Power Management
Item Description
Doze Timer Only DISABLE is permitted.
Sleep Timer Only DISABLE is permitted.
IDE Standby Timer Only DISABLE is permitted.
5.5. How to End the “BIOS SET-UP”
This section describes how to save the information specified in the BIOS set-up and to quit the BIOS
set-up.
1. In case of saving and exiting.
(1) At MENU SCREEN, move the cursor to “Exit Setup” and push [ENTER].
(2) Move cursor to “Yes, save and exit the Setup Utility.” and push [ENTER] and reboot.
2. In case of quitting without saving.
(1) At MENU SCREEN, move the cursor to “Exit Setup” and push [ENTER]
(2) Move to cursor to “No, Exit the Setup Utility without saving.”, and push [ENTER] and reboot.
In case of confirming the parameter before set-up working, press the [F6] key and exit the SETUP
program without saving the set information.
In case of setting new parameter correctly, press the [F4] key to save the values and end the SETUP
program.
IBM SurePath Setup – (C) Copyright IBM Corporation 1994
Power Management
Doze Timer
Sleep Timer
IDE Standby Timer
[ Disable ]
[ Disable ]
[ Disable ]
<F1> Help < >< > Move < > Next Value <F9> Restore Setting
<Esc> Exit < > Previous Value <F10> Default Setting
02 99.07.29 Added this page.
