Step 12. Display the following message on the upper-left screen.
BIOS ROM Writer Ver. 01 1.01 [Card PC ROM:28F010]
FILE READ : 20000
PROGRAM ZERO ADDRESS :
MAX RETRY COUNT :
ERASE VERIFY ADDRESS :
ERASE RETRY COUNT :
PROGRAM ADDRESS :
MAX RETRY COUNT :
Are you sure? (Y/N)
ATTENTION: The BIOS changing actually will start after Step 13. You
must not touch the keyboard or turn off the power by finishing Step 14.
If it is done, the BIOS is broken, and Intelligent Terminal cannot start.
If you input "N" in this step, you can cancel this procedure.
Step 13. Input "Y" for the message "Are you sure? (Y/N)".
Step 14. After that, the number on the screen is changed, and BIOS is updated.
Step 15. If the message "BIOS ROM UPDATE IS COMPLETED" is displayed, finished to update the
BIOS
Step 16. Release this disk.
Step 17. Automatically reboot. Look at the screen, and confirm that the BIOS version number is
changed to 1.09. (Refer to Figure 1.)
Step 18. If the Floppy Disk Drive connects to the Intelligent Terminal, go to Step 22.
Step 19. After the Intelligent Terminal boots, turn off it normally.
Step 20. Disconnect the Floppy Disk Drive.
Step 22. Turn on again. The BIOS's error message is displayed. Exit the setup screen referring to Step
6 and restart the Intelligent Terminal. (In this step, it is not necessary to push [Shift] key)
Step 23. Confirm that the system boots Normally.
Step 24. Finally, turn off, and disconnect the full keyboard.
