Year 2000 issue of Open CNC (A-76040E Edition 02) Additional Manual Page 21

Additional Manual
EDIT
SHEET
DRAW. NO. CUST
TITLE
DESCRIPTIONDESIG.DATE
Year 2000 issue of OPEN CNC
A
-76040E
20
/
Setting Screen of Non-Cacheable Region
Item Sub item Description
Cache
Control
Cache State Select ON/OFF about internal cache.
Usually ON is selected.
ROM
Shadowing
F0000H-FFFFFH
E8000H-EFFFFH
E0000H-E7FFFH
D8000H-DFFFFH
D0000H-D7FFFH
C0000H-CFFFFH
Select ROM shadowing about each area.
FxxxxH Select Enable.
ExxxxH Select Disable.
DxxxxH Select Disable.
CxxxxH Select Enable.
Non Cacheable Region Select cache inhibiting area at D0000H-DFFFFH.
Usually DISABLE is selected.
IBM SurePath Setup – (C) Copyright IBM Corporation 1994
Non-Cacheable Region
Non-Cacheable Region [ Disable ]
<F1> Help < >< > Move < > Next Value <F9> Restore Setting
<Esc> Exit < > Previous Value <F10> Default Setting
02 99.07.29 Added this page.
