Year 2000 issue of OPEN CNC
A
-76040E
8
/
4.3. BIOS SET-UP Items
Standard System Parameters Display
Phoenix SETUP Utility (Version 1.00)
(C)Phoenix Technologies Ltd. 1985, 1992 All Rights Reserved
Page 1 of 3
** Standard System Parameters **
System Time:
12:00:00
System Date: Sep 14, 1993
Diskette A:
3.5” , 1.44 MB
Diskette B: Not Installed Cyl Hd Pre LZ Sec Size
Hard Disk 1: AUTO 1 722 10 0 722 23 81
Hard Disk 2: Not Installed
Base Memory: 640 KB
Extended Memory: 3072 KB
Video Card: VGA/EGA NumLock on at boot: NO
CPU Speed: Fast Quick Boot: Off
Esc
Menu
F2
Sys Info Field
Space/-
Value
PgUp/Dn
Page
- Detailed Description of SET-UP Items
Item Description
System Time:
System Date:
Set time in this field. The format is as follows.
month / day / year
Set date in this field. The format is as follows.
hour : min. : sec.
Diskette A; Set media type of FDD. Select “3.5”, 1.44 MB”.
When it is not used, select “Not Installed”.
Diskette B: Set media type of second FDD. Select “3.5”, 1.44 MB”.
When it is not used, select “Not Installed”.
Hard Disk 1: A type of HDD used in MMC-IV is displayed.
This item has been set as “AUTO 1”.
Hard Disk 2: A type of Second HDD is displayed.
This item has been set as “Not Installed”.
Base Memory: Base memory size that detected by POST is displayed.
Do not change this parameter.
Extended Memory: Extended memory size that detected by POST is displayed.
Do not change this parameter.
Video Card: Set Video type. This item has been set as “VGA/EGA”.
Do not change this parameter.
Select CPU speed.CPU Speed:
Fast :
Slow :
Full speed
Slow speed
Select ON/OFF of keyboard NumLock at boot.NumLock on at boot
Yes :
No :
NumLock ON at boot.
NumLock OFF at boot.
Select ON/OFF of Quick BootQuick Boot
Off :
On :
Memory test runs at boot.
Memory test does not run at boot.
02 99.07.29 Added this page.
