Year 2000 issue of Open CNC (A-76040E Edition 02) Additional Manual Page 15

Additional Manual
EDIT
SHEET
DRAW. NO. CUST
TITLE
DESCRIPTIONDESIG.DATE
Year 2000 issue of OPEN CNC
A
-76040E
14
/
(2) Device and I/O Ports
Setting Screen of Device and I/O Ports
The parameters of I/O devices. The descriptions are shown in below table.
Item Description
Serial Port A I/O Address Parameter of serial port A I/O address and IRQ.
Set “3F8-IRQ4” normally.
Serial Port B I/O Address Parameter of serial port B I/O address and IRQ.
Set “2F8-IRQ3” normally.
Parallel Port I/O Address Parameter of parallel port I/O address and IRQ.
Set “3BC-IRQ7” normally.
Parallel Port Mode Set parallel port mode (Standard=AT mode, Extended=PS/2
mode).
Set “Standard” normally.
Parallel Port Extended
Mode
If Extended is selected in upper items, Bi-directional will be
set.
Mouse The connection status of mouse.
Diskette Drive A Set media type of drive A.
Diskette Drive B Set media type of drive B.
Video Setup… Video chip type is displayed. This can not be changed.
IDE Drives Setup… HDD size is displayed. This can not be changed.
IBM SurePath Setup – (C) Copyright IBM Corporation 1994
Device and I/O Ports
Serial Port A Address
Serial Port B Address
Parallel Port
Parallel Port Mode
Parallel Port Extended Mode
Mouse
Diskette Drive A:
Diskette Drive B:
・ Video Setup …
・ IDE Drives Setup
…
[ 3F8h-IRQ4 ]
[ 2F8h-IRQ3 ]
[ 3BCh-IRQ7 ]
[ Standard ]
[ ]
[ Not Installed ]
[ 1.44 MB 3.5” ]
[ Not installed ]
<F1> Hel
p
< >< > Move < > Next Value <F9> Restore Settin
g
02 99.07.29 Added this page.
