Year 2000 issue of Open CNC (A-76040E Edition 02) Additional Manual Page 12

Additional Manual
EDIT
SHEET
DRAW. NO. CUST
TITLE
DESCRIPTIONDESIG.DATE
Year 2000 issue of OPEN CNC
A
-76040E
11
/
4.4. How to end the set-up.
Pressing the [Esc] key on the set-up menu causes the Exiting SETUP menu to appear on the right
section of the screen.
(1) Press the [ESC] key to continue with SETUP.
(2) Press the [F4] key to save the set information and end the set-up program. After the set-up
program ends, the MMC-IV is reset, and the system is booted again.
(3) Press the [F5] key to load default values for all pages.
(4) Press the [F6] key to abort SETUP without saving the set information
In case of confirming the parameter before set-up working, press the [F6] key and exit the SETUP
program without saving the set information.
In case of setting new parameter correctly, press the [F4] key to save the values and end the set-
up program.
** Exiting SETUP **
Continue with SETUP.
Save values, exit
setup, and reboot.
Load default values
for all pages.
Abort SETUP without
saving values.
ESC
F4
F5
F6
Inadvertently pressing the F5 key loses the factory
settings of the MMC-IV, possibly causing a failure.
02 99.07.29 Added this page.
