Year 2000 issue of Open CNC (A-76040E Edition 02) Additional Manual Page 11

Additional Manual
EDIT
SHEET
DRAW. NO. CUST
TITLE
DESCRIPTIONDESIG.DATE
Year 2000 issue of OPEN CNC
A
-76040E
10
/
Management Feature Control Display
Phoenix SETUP Utility (Version 1.00)
(C)Phoenix Technologies Ltd. 1985, 1992 All Rights Reserved
Page 3 of 3
** Power Management Feature Control **
Power Management Disabled
System Doze After: Disabled Hard Disk Off After: Disabled
System Standby After: Disabled LCD Panel Off Time: Disabled
System Suspend After: 15 minute
Suspend Mode: Suspend/Resume
System Doze Speed: Divide by 2 Low Battery Action: Divide by 2
System Standby Speed: Divide by 2
Esc
Menu
F2
Sys Info Field
Space/-
Value
PgUp/Dn
Page
- Detailed Description of SET-UP Items
Item Description
Power Management : Only “Disabled” is permitted.
02 99.07.29 Added this page.
