  2. Year 2000 issue of Open CNC (A-76040E Edition 02)

Year 2000 issue of Open CNC (A-76040E Edition 02) Additional Manual Page 17

Additional Manual
EDIT
SHEET
DRAW. NO. CUST
TITLE
DESCRIPTIONDESIG.DATE
Year 2000 issue of OPEN CNC
A
-76040E
16
/
Setting screen of “Power-on Password”
Setting screen of “Administrator Password”
IBM SurePath Setup – (C) Copyright IBM Corporation 1994
Power-on Password
Enter your new power-on password twice.
Enter Power-on Password.
Enter Power-on Password Again.
Set or Change Power-on Password.
Delete Power-on Password.
Password Prompt
[ ]
[ ]
[ on ]
<F1> Help < > Move
<Esc> Exit
IBM SurePath Setup – (C) Copyright IBM Corporation 1994
Administrator Password
Enter your new administrator password twice.
Enter Administrator Password.
Enter Administrator Password Again.
Set or Change Administrator Password.
Delete Administrator Password.
Password Prompt
[ ]
[ ]
[ on ]
<F1> Help < > Move
<Esc> Exit
02 99.07.29 Added this page.
