Year 2000 issue of Open CNC (A-76040E Edition 02) Additional Manual Page 20

Additional Manual
EDIT
SHEET
DRAW. NO. CUST
TITLE
DESCRIPTIONDESIG.DATE
Year 2000 issue of OPEN CNC
A
-76040E
19
/
(6) Advanced Setup
Menu Screen of Advanced Setup
Setting Screen of Cache Control
Setting Screen of ROM Shadowing
IBM SurePath Setup – (C) Copyright IBM Corporation 1994
ROM Shadowing
F0000h – FFFFFh
E8000h – EFFFFh
E0000h – E7FFFh
D8000h – DFFFFh
D0000h – D7FFFh
C0000h – CFFFFh
[ Enabled ]
[ Disabled ]
[ Disabled ]
[ Disabled ]
[ Disabled ]
[ Enabled ]
<F1> Help < >< > Move < > Next Value <F9> Restore Setting
<Esc> Exit < > Previous Value <F10> Default Setting
IBM SurePath Setup – (C) Copyright IBM Corporation 1994
Advanced Setup
Warning:
Items on the following menus control advanced hardware features.
If they are configured incorrectly, the system might malfunction.
- Cache Control
- ROM Shadowing
- Non-Cacheable Region
<F1> Help < > Move
<Esc> Exit <Enter> Select
02 99.07.29 Added this page.
IBM SurePath Setup – (C) Copyright IBM Corporation 1994
Cache Control
<F1> Help < >< > Move < > Next Value <F9> Restore Setting
<Esc> Exit < > Previous Value <F10> Default Setting
