Year 2000 issue of OPEN CNC
A
-76040E
2
/
2.2. Intelligent Terminal type 1
A following Intelligent Terminal type 1 has possibility that Year 2000 issue occurs. This issue doesn’t
occur with BIOS version 1.09 and after.
Order specifications:
A13B-0172-B001, A13B-0172-B002, A13B-0172-B021, A13B-0172-B022,
A13B-0172-B031, A13B-0172-B032, A13B-0172-B101, A13B-0172-B102,
A13B-0172-B121, A13B-0172-B122, A13B-0172-B131, A13B-0172-B132,
A13B-0172-B141, A13B-0172-B142, A13B-0174-B102
Unit specifications:
A13B-0172-C001, A13B-0172-C002, A13B-0172-C003, A13B-0172-C004,
A13B-0172-C005, A13B-0172-C006, A13B-0172-C021, A13B-0172-C022,
A13B-0172-C023, A13B-0172-C024, A13B-0172-C025, A13B-0172-C026,
A13B-0172-C031, A13B-0172-C032, A13B-0172-C033, A13B-0172-C034,
A13B-0172-C035, A13B-0172-C036, A13B-0172-C101, A13B-0172-C102,
A13B-0172-C103, A13B-0172-C104, A13B-0172-C105, A13B-0172-C106,
A13B-0172-C121, A13B-0172-C122, A13B-0172-C123, A13B-0172-C124,
A13B-0172-C125, A13B-0172-C126, A13B-0172-C131, A13B-0172-C132,
A13B-0172-C133, A13B-0172-C134, A13B-0172-C135, A13B-0172-C136,
A13B-0172-C145, A13B-0172-C146, A13B-0174-C102, A13B-0174-C104,
A13B-0174-C106
BIOS version: 1.08 and former
It is possible to confirm the BIOS version on the startup screen. The BIOS version is displayed at 4
th
line as follows.
Startup screen
(C) Copyright IBM Corporation 1981,1994 ALL RIGHTS RESERVED
486DX2-50MHz
Copyright (C) Matsushita Electric Industrial Co.,LTD 1995
Release 01 1.02
0640KB System Memory
7168KB Extended Memory
