Year 2000 issue of Open CNC (A-76040E Edition 02) Additional Manual Page 18

Additional Manual
EDIT
SHEET
DRAW. NO. CUST
TITLE
DESCRIPTIONDESIG.DATE
Year 2000 issue of OPEN CNC
A
-76040E
17
/
Password setting and right of access.
Item Sub item Description
Hard Disk Access Only “Enable” (default value) is permitted.Secure Hard
Disk Drives and
Diskette Drives
Diskette Drive Access If “disable” is set, access to connected FDD is
impossible.
Enter Power-on
Password
Input power-on password. More than 7 characters
are needed.
Enter Power-on
Password Again
Input same characters for power-on password.
Set or change Power-on
password
Select Enter after password input twice for setting
and changing password.
Delete Power-on
Password
Select Enter for deleting password.
Power-on
Password
Password Prompt Select OFF for changing password unnecessary at
boot (password at BIOS set-up is necessary).
Enter Administrator
Password
Input administrator power-on password. More
than 7 characters are needed.
Enter Administrator
Password Again
Input same characters for administrator password.
Set or change
Administrator password
Select Enter after password input twice for setting
and changing password.
Delete Administrator
Password
Select ENTER for deleting password.
Administrator
Password
Power-on password
changeable by user
Select YES for permitting to change power-on
password.
Note: Administrator password is superior to power-on password. If both passwords are set, BIOS set-
up with power-on password will run at only items of “System Security” and “Power-on
password”.
Both passwords are available for password at boot.
02 99.07.29 Added this page.
