H. PARAMETERS
B–62093E–1/02
APPENDIX
210
#7 #6 #5 #4 #3 #2 #1 #0
9004 CUTLG NOP_B
NOP_B 0 : When no other address is specified in a block that calls a
subprogram by a T or M code, the block is executed.
1 : The block is not executed.
CUTLG 0 : Does not count cutting distance
1 : Count cutting distance
#7 #6 #5 #4 #3 #2 #1 #0
9005 TMACC AXCLS AX4CL AX3CL AX2CL AX1CL
AX1CL 0 : Subprogram call by the 1st address is invalid
1 : Subprogram call by the 1st address is valid
AX2CL 0 : Subprogram call by the 2nd address is invalid
1 : Subprogram call by the 2nd address is valid
AX3CL 0 : Subprogram call by the 3rd address is invalid
1 : Subprogram call by the 3rd address is valid
AX4CL 0 : Subprogram call by the 4th address is invalid
1 : Subprogram call by the 4th address is valid
AXCLS 0 : Always program O9009 is called irrespective of specified
axes.
1 : The program number to be called depends on a specified
axis:
Program O9031 is called when 1st axis is specified.
Program O9032 is called when 2nd axis is specified.
::
Program O9038 is called when 8th axis is specified.
TMACC 0 : Macro call by T code is invalid
1 : Macro call by T code is valid
