FANUC POWER MATE i-MODEL D/H Macro Compiler/Macro Executer Programming manual Page 226

Programming manual
I. ERROR CODES
B–62093E–1/02
APPENDIX
220
The table below indicates the error codes that may occur in compile
processing.
Compile Error Codes (1/2)
Error code
Meaning
0201 There are more than 400 programs.
0202 There is no program.
1001 Block delete number contains decimal point.
1002 Block delete number other than 1 to 9 is coded.
1003 Program number is coded not at start of program.
1004 Sequence number is coded not at start of block.
1005 NC statement has format error.
1006 Code other than EOB is present at end of macro statement.
1007 Equal sign cannot be found with macro statement.
1008 DO nesting depth exceeded 3 levels.
1009 Relation operator cannot be found in conditional expression.
100A IF is not followed by GOTO.
100B Closing bracket (]) cannot be found for IF [<conditional–expression>].
100C GOTO n is followed by code other than EOB.
100D DO m is followed by code other than EOB.
100E END m is followed by code other than EOB.
100F Identification number of END does not match DO.
1010 END to match DO cannot be found.
1011 WHILE is not followed by DO.
1012 Closing bracket (]) cannot be found for WHILE [<conditional–
expression>].
1013 Block not identifiable as NC statement or macro statement is present.
1014 DO to match END cannot be found.
1015 Program number of directory does not match program number in
program.
1016 Program number is missing at start of program.
1201 Nesting depth of parentheses exceeded 5 levels.
1202 Closing bracket (]) cannot be found for #[<expression>].
1203 Closing bracket (]) cannot be found for [<expression>].
1204 Second opening bracket ([) cannot be found for ATAN [<expression>]/
[<expression>].
1205 Slash (/) cannot be found for ATAN [<expression>]/[<expression>].
1206 First closing bracket (]) cannot be found for ATAN [<expression>]/
[<expression>].
1207 Closing bracket (]) cannot be found for function [<expression>].
1208 Format of <expression> contains error.
1209 Format of <expression> on left side of assignment statement contains
error.
120A Format of <expression> in <address>[<expression>], <address>–
[<expression>], or GOTO [<expression>] contains error.
1401 Numeric value longer than 8 digits is present.
1402 Decimal point is followed by code other than number.
1403 Macro variable number is longer than 6 digits.
I.2
COMPILE ERROR
CODE TABLE
(FOR PERSONAL
COMPUTER)
