B-65285EN/03 TROUBLESHOOTING 2.ALARM NUMBERS AND BRIEF DESCRIPTIONS
- 83 -
2.2.2 Spindle Alarm
Alarm No. SPM PSM Description Remarks
9001 7n01 01 Motor overheat 3.4.1
9002 7n02 02 Excessive speed deviation 3.4.2
9003 7n03 03 DC link fuse blown 3.4.3
9004 7n04 04 E Open phase in the converter main power supply 3.1.10
9006 7n06 06 Temperature sensor disconnected 3.4.4
9007 7n07 07 Excessive speed 3.4.5
9009 7n09 09 Main circuit overload/IPM overheat 3.4.6
9011 7n11 11 7 Converter: DC link overvoltage 3.1.7
9012 7n12 12 DC link overcurrent/IPM alarm
3.4.7
3.5.1
9015 7n15 15 Output switching/spindle switching alarm 3.4.8
750 18 Program sum check error 3.4.9
750 19 Excessive offset of the phase U current detection circuit 3.4.10
750 20 Excessive offset of the phase V current detection circuit 3.4.10
9021 7n21 21 Position sensor polarity setting incorrect 3.4.11
749 24 Serial transfer data error 3.4.12
9027 7n27 27 Position coder disconnected 3.4.13
9029 7n29 29 Short-period overload 3.4.14
9030 7n30 30 1 Overcurrent in the converter input circuit 3.1.1
9031 7n31 31 Motor lock alarm 3.4.15
9032 7n32 32 Serial communication LSI RAM error 3.4.16
9033 7n33 33 5 Converter: DC link precharge failure 3.1.5
9034 7n34 34 Parameter data out of the specifiable range 3.4.17
9035 7n35 35 Gear ratio parameter error 3.5.2
9036 7n36 36 Error counter overflow 3.4.18
9037 7n37 37 Speed detector parameter error 3.4.19
9041 7n41 41 Position coder one-rotation signal detection error 3.4.20
9042 7n42 42 Position coder one-rotation signal not detected 3.4.21
9046 7n46 46
Position sensor one-rotation signal detection error during
thread cutting
3.4.22
9047 7n47 47 Position coder signal error 3.4.23
9050 7n50 50
Excessive speed command calculation value during spindle
synchronization
3.4.24
9051 7n51 51 4 Converter: DC link undervoltage 3.1.4
9052 7n52 52 ITP signal error I 3.4.25
9053 7n53 53 ITP signal error II 3.4.25
9054 7n54 54 Current overload alarm 3.4.26
9055 7n55 55 Abnormal switching status of power leads 3.4.27
9056 7n56 56 Internal cooling fan stopped 3.4.28
9057 7n57 57 H Converter: excessive deceleration power 3.1.11
9058 7n58 58 3 Converter: main circuit overload 3.1.3
9059 7n59 59 2 Converter: cooling fan stopped 3.1.2
9066 7n66 66 Communication alarm between spindle and amplifier 3.4.29
9069 7n69 69 Safety speed exceeded 3.4.30
9070 7n70 70 Abnormal axis data 3.4.31
9071 7n71 71 Abnormal safety parameter 3.4.32
9072 7n72 72 Motor speed mismatch 3.4.33
9073 7n73 73 Motor sensor disconnected 3.4.34
9074 7n74 74 CPU test alarm 3.4.35
