AC Servo Motor Alpha i/is Series, Maintenance manual Page 193

Maintenance manual
B-65285EN/03 MOTOR MAINTENANCE 2.SPINDLE MOTOR MAINTENANCE
- 163 -
2.2 MAINTENANCE PARTS
(1) Parts of the terminal box (α
αα
αi, α
αα
αiP, and α
αα
αCi series)
Model
Terminal box
assembly
Lid of terminal
box
α1/10000i, α1/15000i
α1.5/10000i, α1.5/15000i
αC1/6000i
A290-1402-T400 A290-0853-V410
α2/10000i, α2/15000i
α3/10000i, α3/12000i
αC2/6000i, αC3/6000i
A290-1404-T400 A290-0853-V410
α6/10000i to α15/7000i
α6/12000i to α15/10000i
α12/6000i
P to α22/6000iP
α12/8000iP to α22/8000iP
αC6/6000i to αC15/6000i
A290-1406-T400 A290-0854-V410
α18/7000i, α22/7000i
A290-1410-T400 A290-1410-V410
α18/10000i, α22/10000i
α30/6000i
P to α50/6000iP
A290-1410-T401 A290-1410-V410
α60/4500iP
A290-0833-T400 A290-1040-X402
NOTE
The above table may not apply to motors of which
motor drawing number ends with B9xx. Contact
your FANUC service representative.
(2) Parts of the terminal box (α
αα
αiT and α
αα
αiL series)
Model
Terminal box
assembly
Lid of terminal
box
α1.5/15000iT
A290-1402-T400 A290-0853-V410
α2/15000iT, α3/12000iT
A290-1404-T400 A290-0853-V410
α6/12000iT, α8/12000iT
α8/15000iT, α15/10000iT
A290-1406-T400 A290-0854-V410
α8/20000iL
A290-1487-T400 A290-0854-V410
α15/12000iT
A290-1410-T402 A290-1410-V410
α22/10000iT
A290-1410-T401 A290-1410-V410
α15/15000iL, α26/15000iL
A290-1489-T400 A290-1410-V410
NOTE
The above table may not apply to motors of which
motor drawing number ends with B9xx. Contact
your FANUC service representative.
