AC Servo Motor Alpha i/is Series, Maintenance manual Page 61

Maintenance manual
B-65285EN/03 START-UP PROCEDURE 4.CONFIRMATION OF THE OPERATION
- 31 -
4.3.2 Troubleshooting at Startup
4.3.2.1 The PIL LED (power-on indicator) is off.
(1) When the PIL LED on the spindle amplifier module does not
come on after the main circuit breaker is turned on
No. Cause of trouble Check method Action
1
The 200-V control power is
not supplied.
The PSM PIL lamp is off.
Check the cable attached to
CX1A of PSM.
2 The cable is defective. The PSM PIL lamp is on.
Check the cable attached to
the connector CXA2A/B.
3
The power is externally
connected to 0 V, GND, or
the like.
When the connector is
detached, the PIL lamp is on.
Replace or repair the cable.
4
There is a blown fuse on the
printed circuit board.
If the fuse blows, the printed
circuit board may be faulty.
Replace the unit.
5
The printed circuit board is
defective.
Even when all cables except
the cable attached to
connector CX2A/B are
detached, the PIL lamp does
not come on.
Replace the unit.
