4.3.2.7 Cutting power weakens or acceleration/deceleration slows
down.
(1) When the load meter does not indicate the maximum output
A. A mechanical cause such as a belt slip may occur.
(2) When the load meter indicates the maximum output
A. Check whether the torque limit signal is input incorrectly.
FS15i FS16i
#7 #6 #5 #4 #3 #2 #1 #0
G227 G070 TLMHA TLMLA
B. If you are using the BZi sensor, it is likely that a slip has
occurred between the sensor gear and spindle (on
acceleration).
C. Check that the motor part number matches its parameters.
For details, refer to Appendix A in "FANUC AC SPINDLE
MOTOR αi series Parameter Manual (B-65280EN)."
D. Check whether the output limit pattern is set incorrectly.
For details, refer to Chapter 1 in "FANUC AC SPINDLE
MOTOR αi series Parameter Manual (B-65280EN)."
