AC Servo Motor Alpha i/is Series, Maintenance manual Page 118

Maintenance manual
3.TROUBLESHOOTING AND ACTION TROUBLESHOOTING B-65285EN/03
- 88 -
3.1.5 Alarm Code 5 (PSM, PSMR)
(1) Meaning
The main circuit capacitor was not recharged within the specified
time.
(2) Cause and troubleshooting
(a) Too many SVM and/or SPM units are connected.
→ Check the specification of the PSM.
(b) The DC link is short-circuited.
→ Check the connection.
(c) The recharge current limiting resistor is defective.
→ Replace the distributing board.
3.1.6 Alarm Code 6 (PSM, PSMR)
(1) Meaning
The control power supply voltage decrease.
(2) Cause and troubleshooting
(a) Input voltage decrease
→ Check the power supply.
3.1.7 Alarm Code 7 (PSM, PSMR)
(1) Meaning
In the main circuit, the DC voltage at the DC link is abnormally
high.
(2) Cause and troubleshooting
(a) Excessive regenerated power
The PSM does not have a sufficient capacity.
→ Check the specification of the PSM.
(b) The output impedance of the AC power source is too high.
→ Check the power source output impedance.
(Normal if the voltage variation at maximum output
time is within 7%)
(c) The main circuit power supply may have been switched off
with an emergency stop state released.
→ Check the sequence.
