2.3 ALLOWABLE RADIAL LOAD
(1) α
αα
αi, α
αα
αiP, and α
αα
αCi series
Use motor output axes under the allowable radial load listed below or
less:
Allowable radial load
Model
Output axis end Center of output axis
α0.5/10000i
294N (30kgf) 323N (33kgf)
α1/10000i, αC1/6000i
392N (40kgf) 441N (45kgf)
α1.5/10000i
882N (90kgf) 980N (100kgf)
α2/10000i, αC2/6000i
882N (90kgf) 999N (102kgf)
α3/10000i, αC3/6000i
1470N (150kgf) 1607N (164kgf)
α6/10000i, αC6/6000i
1960N (200kgf) 2205N (225kgf)
α8/8000i, αC8/6000i
2940N (300kgf) 3371N (344kgf)
α12/7000i, α15/7000i
α12/6000iP, α15/6000iP
αC12/6000i, αC15/6000i
2940N (300kgf) 3410N (348kgf)
α18/7000i, α22/7000i
α18/6000iP, α22/6000iP
4410N (450kgf) 4988N (509kgf)
α30/6000i, α40/6000i
α30/6000iP, α40/6000iP
α50/6000iP
5390N (550kgf) 6134N (626kgf)
α50/4500i
1078N (1100 kgf) 1230N (1255 kgf)
α60/4500iP
- 19600N (2000kgf)
α1/15000i, α1.5/15000i
α2/15000i
Direct connection to the spindle
α3/12000i
980N (100kgf) 1068N (109kgf)
α6/12000i
1470N (150kgf) 1656N (169kgf)
α8/10000i
1960N (200kgf) 2244N (229kgf)
α12/10000i, α15/10000i
α12/8000iP, α15/8000iP
2450N (250kgf) 2842N (290kgf)
α18/10000i, α22/10000i
α18/8000i
P, α22/8000iP
2940N (300kgf) 3332N (340kgf)
