1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63834EN/02

- 646 -

MDII key panel), and then press the “INSERT” key on the MDI key

panel. After inserting the line of code into the part program, the editor

screen with our new command inserted will be displayed. To prepare

for further program development, let’s move the cursor position to the

G01X1.Z1. block.

Commands such as interpolation, plane select, and mode switch can

all be entered using the method mentioned above. Remember to use

the “INSERT” key on the MDI key panel to insert any information

that is in the buffer into the part program. Failure to do so will result

in the buffered information being lost.

O0015 ;

F300.;

M7;

G01X1.Z1.;

[PROCESS][G CODE][M CODE][CYCLE][CONTUR]
