B-63834EN/02 MANUAL GUIDE 0i 1.MANUAL GUIDE 0i
- 651 -
and then pressing “INPUT.” Then, by pressing the “ACCEPT” soft-
key, the original canned cycle block is changed to new one.
The canned cycles provided by MANUAL GUIDE 0
i are configured
as a pair of a machining type block and figure block. So, after
entering a machining type block, such as G1130, on the editor screen,
press “CYCLE” and then select figure block G-code, G1460 to G1461.
For example, a canned cycle program would be entered as follows.
G1130 F0.2 E15. Q2.5 H1. K1. W1. ;
G460 X50. Z-50. U50. D15. W15. ;
NOTE
MANUAL GUIDE 0i canned cycles must be entered
as a pair of machining type block and figure block.
Only one figure block can be entered for each
machining type block.
