APPENDIX

B–63834EN/02

G. ALARM LIST

761

9) Rigid tapping alarm

Number Message Contents

740 RIGID TAP ALARM : EXCESS

ERROR

During rigid tapping, the position deviation of the spindle in the stop state

exceeded the setting.

741 RIGID TAP ALARM : EXCESS

ERROR

During rigid tapping, the position deviation of the spindle in the stop state

exceeded the setting.

742 RIGID TAP ALARM : LSI OVER FLOW During rigid tapping, an LSI overflow occurred on the spindle side.

10) Spindle alarms

Number Message Contents

749 S–SPINDLE LSI ERROR It is serial communication error while system is executing after power

supply on. Following reasons can be considered.

1) Optical cable connection is fault or cable is not connected or cable

is cut.

2) MAIN CPU board or option 2 board is fault.

3) Spindle amp. printed board is fault.

If this alarm occurs when CNC power supply is turned on or when

this alarm can not be cleared even if CNC is reset, turn off the power

supply also turn off the power supply in spindle side.

750 SPINDLE SERIAL LINK START

FAULT

This alarm is generated when the spindle control unit is not ready for

starting correctly when the power is turned on in the system with the

serial spindle.

The four reasons can be considered as follows:

1) An improperly connected optic cable, or the spindle control unit’s

power is OFF.

2) When the NC power was turned on under alarm conditions other

than SU–01 or AL–24 which are shown on the LED display of the

spindle control unit.

In this case, turn the spindle amplifier power off once and perform

startup again.

3) Other reasons (improper combination of hardware)

This alarm does not occur after the system including the spindle con-

trol unit is activated.

4) The second spindle (when SP2, bit 4 of parameter No. 3701, is 1)

is in one of the above conditions 1) to 3).

See diagnostic display No. 409 for details.

752 FIRST SPINDLE MODE CHANGE

FAULT

This alarm is generated if the system does not properly terminate a

mode change. The modes include the Cs contouring, spindle position-

ing, rigid tapping, and spindle control modes. The alarm is activated if

the spindle control unit does not respond correctly to the mode change

command issued by the NC.

754 SPINDLE–1 ABNORMAL TORQUE

ALM

Abnormal first spindle motor load has been detected.

762 SECOND SPINDLE MODE

CHANGE FAULT

Refer to alarm No. 752. (For 2nd axis)

764 SPINDLE–2 ABNORMAL TORQUE

ALM

Same as alarm No. 754 (for the second spindle)
