APPENDIX

B–63834EN/02

G. ALARM LIST

755

4) Serial pulse coder (SPC) alarms

No. Message Description

360 n AXIS : ABNORMAL CHECKSUM

(INT)

A checksum error occurred in the built–in pulse coder.

361 n AXIS : ABNORMAL PHASE DATA

(INT)

A phase data error occurred in the built–in pulse coder.

362 n AXIS : ABNORMAL REV.DATA

(INT)

A rotation speed count error occurred in the built–in pulse coder.

363 n AXIS : ABNORMAL CLOCK (INT) A clock error occurred in the built–in pulse coder.

364 n AXIS : SOFT PHASE ALARM (INT) The digital servo software detected invalid data in the built–in pulse cod-

er.

365 n AXIS : BROKEN LED (INT) An LED error occurred in the built–in pulse coder.

366 n AXIS : PULSE MISS (INT) A pulse error occurred in the built–in pulse coder.

367 n AXIS : COUNT MISS (INT) A count error occurred in the built–in pulse coder.

368 n AXIS : SERIAL DATA ERROR

(INT)

Communication data from the built–in pulse coder cannot be received.

369 n AXIS : DATA TRANS. ERROR

(INT)

A CRC or stop bit error occurred in the communication data being re-

ceived from the built–in pulse coder.

380 n AXIS : BROKEN LED (EXT) The separate detector is erroneous.

381 n AXIS : ABNORMAL PHASE

(EXT LIN)

A phase data error occurred in the separate linear scale.

382 n AXIS : COUNT MISS (EXT) A pulse error occurred in the separate detector.

383 n AXIS : PULSE MISS (EXT) A count error occurred in the separate detector.

384 n AXIS : SOFT PHASE ALARM

(EXT)

The digital servo software detected invalid data in the separate detector.

385 n AXIS : SERIAL DATA ERROR

(EXT)

Communication data from the separate detector cannot be received.

386 n AXIS : DATA TRANS. ERROR

(EXT)

A CRC or stop bit error occurred in the communication data being re-

ceived from the separate detector.

387 n AXIS : ABNORMAL ENCODER

(EXT)

An error occurs in the separate detector. For details, contact the

manufacturer of the scale.

202

CSA

BLA

PHA

PCA

BZA

CKA

SPH

#6 (CSA) : Check sum alarm has occurred.

#5 (BLA) : Battery low alarm has occurred.

#4 (PHA) : Phase data trouble alarm has occurred.

#3 (PCA) : Speed count trouble alarm has occurred.

#2 (BZA) : Battery zero alarm has occurred.

#1 (CKA) : Clock alarm has occurred.

#0 (SPH) : Soft phase data trouble alarm has occurred.

D The details of serial

pulse coder alarm
