1.MANUAL GUIDE 0i MANUAL GUIDE 0i B-63834EN/02

- 686 -

Data item Comment

PASS POINT W Z coordinate of the 2nd passing point on the line

SHIFT DIST. D When the line should be specified by shifting an original

line, enter the shifting

SHIFT DIRC. Select a shifting direction by arrow soft-keys

- Cross point between line and arc

The cross point between a line and arc can be calculated. For the line,

one that has been shifted through some distance can be used for the

calculation.

This is useful for entering a tool path that has been shifted from the

original figure by an amount equal to the tool radius.

(a) When specifying a line with one point and an angle

Initially, the following data items are displayed for the Line.

Data item Comment

PASS POINT X X coordinate of the 1st passing point on the line

PASS POINT Z Z coordinate of the 1st passing point on the line

ANGLE A Angle of line from +Z-axis. A positive angle is counter

clockwise direction.

SHIFT DIST. D When the line should be specified by shifting an original

line, enter the shifting

SHIFT DIRC. Select a shifting direction by arrow soft-keys

By pressing [NEXT] after entering the necessary data, the

following screen for the Arc is displayed. By pressing [PREV.],

you can return to the previous screen for the Line.

By pressing [NEXT] after entering the necessary data, a similar

data item screen for Line-2 is displayed. By pressing [PREV.],

you can return to the previous screen for Line-1.

Data item Comment

CENTER I X coordinate of an arc center

CENTER K Z coordinate of an arc center

RADIUS R Radius of an arc, but plus value only

SELECT Select necessary cross point from two possible points

by arrow soft-keys

(b) When specifying a line with two points

By pressing [XZ,XZ], you can specify a line with two passing

points.

By pressing [XZ, A], you can select the above type using an

angle again.

Data item Comment

PASS POINT X X coordinate of the 1st passing point on the line

PASS POINT Z Z coordinate of the 1st passing point on the line

PASS POINT U X coordinate of the 2nd passing point on the line

PASS POINT W Z coordinate of the 2nd passing point on the line

SHIFT DIST. D When the line should be specified by shifting an original

line, enter the shifting distance

SHIFT DIRC. Select a shifting direction by arrow soft-keys

Data screen for the arc is displayed quite similar to the case of i).
