GENERAL1. GENERAL

B–63004EN/02

This manual uses the following symbols:

Indicates a combination of axes such as X__ Y__ Z

(used in PROGRAMMING.).

Indicates the end of a block. It actually corresponds to

the ISO code LF or EIA code CR.

;

The table below lists manuals related to MODEL C of Series 16i, Series

18i, Series 160i and Series 180i.

In the table, this manual is marked with an asterisk (*).

Table 1 Related Manuals

Manual name

Specification

number

DESCRIPTIONS B–63002EN

CONNECTION MANUAL (HARDWARE) B–63003EN

CONNECTION MANUAL (FUNCTION) B–63003EN–1

OPERATOR’S MANUAL (For LATHE) B–63004EN *

OPERATOR’S MANUAL (For MACHINING CENTER) B–63014EN

MAINTENANCE MANUAL B–63005EN

PARAMETER MANUAL B–63010EN

CONNECTION MANUAL (LOADER CONTROL) B–62443EN–2

PROGRAMMING MANUAL

(Macro Compiler / Macro Executer)

B–61803E–1

FAPT MACRO COMPILER PROGRAMMING MANUAL B–66102E

FAPT LADDER–II OPERATOR’S MANUAL B–66184EN

FANUC PMC–MODEL SAI/SAS PROGRAMMING

MANUAL (LADDER LANGUAGE)

B–61863E

FANUC PMC–MODEL SC/NB PROGRAMMING

MANUAL (C LANGUAGE)

B–61863E–1

FANUC Super CAP T/I T OPERATOR’S MANUAL B–62444E–1

FANUC Super CAP M/II M OPERATOR’S MANUAL B–62154E

CONVERSATIONAL AUTOMATIC PROGRAMMING

FUNCTION II FOR LATHE OPERATOR’S MANUAL

B–62153E

CONVERSATIONAL AUTOMATIC PROGRAMMING

FUNCTION II FOR LATHE OPERATOR’S MANUAL

B–61804E–2

FANUC Symbol CAPi T OPERATOR’S MANUAL B–63304EN

FANUC Super CAPi T OPERATOR’S MANUAL B–63284EN

FANUC Super CAPi M OPERATOR’S MANUAL B–63294EN

Special symbols

Related manuals
