8. DATA INPUT/OUTPUT

B–63004EN/02

OPERATION

612

The file name used for save operation is determined by the amount of

SRAM mounted in the CNC. A file holding saved data is divided into

blocks of 512KB.

HEAD1 SRAM file

Amount of SRAM 256 KB 0.5 MB 1.0 MB 2.5 MB

Number of files 1

SRAM256A. FDB SRAM0_5A. FDB SRAM1_0A. FDB

SRAM1_0B. FDB

SRAM2_5A. FDB

SRAM2_5B. FDB

SRAM2_5C. FDB

SRAM2_5D. FDB

SRAM2_5E. FDB

HEAD2 SRAM file

Amount of SRAM

256 KB 0.5 MB 1.0 MB 2.5 MB

Number of files 1

SRAM256A. OP2 SRAM0_5A. OP2 SRAM1_0A. OP2

SRAM1_0B. OP2

SRAM2_5A. OP2

SRAM2_5B. OP2

SRAM2_5C. OP2

SRAM2_5D. OP2

SRAM2_5E. OP2

To cancel file save prior to its completion, press the

RESET

key on the MDI

panel.

When the memory card has less than 512K bytes of free space, a memory

card replacement request is displayed. Insert a new memory card.

CNC memory data that has been saved to a memory card can be loaded

(restored) back into CNC memory.

CNC memory data can be loaded in either of two ways. In the first

method, all saved memory data is loaded. In the second method, only

selected data is loaded.

Explanations

D File name

D Canceling saving

D Memory card

replacement request

Loading data into

memory (restoration)
