0i/0i Mate - Model C Maintenance manual Page 119

Maintenance manual
B–64115EN/01
1. DISPLAY AND OPERATION
95
NOTE
With parameter No. 3121, choose whether the sixth–type
sampling data is thermal simulation data or spindle load
meter data. When spindle load meter is selected, the
spindle data of the first axis is stored with each path.
(4)Sampling axis: The axes along which data will be sampled are
displayed.
(5)Sampling period: The sampling period for each axis is displayed.
(6)Date of storage: While data is being sampled, MEMORY blinks in this
field. When data sampling stops, the date at that point appears in this
field.
Waveform diagnosis data of servo alarm format can be output to an I/O
device, as follows:
1) Select EDIT mode.
2) Press the
SYSTEM
key, then display the WAVE DIAGNOS. (MEMORY)
screen.
3) Press the [W.MEM],
, [PUNCH], and [EXEC] soft keys, in this
order.
For details of input/output to/from the FANUC Floppy Cassette or FA
Card, see “Output to FANUC Floppy Cassette or FA Card,” below.
WAVE DIAGNOSE (MEMORY) O1234 N12345
CONDIGION: 100 TRIGGER: G0123.4
DATA KINDS SAMPLING AXIS
POS ERROR XYZA
MOTION CMD XYZA
CURRENT (%) XYZA
SPEED (RPM) NONE
TORQUE CMD NONE
HEAT SIMLT XYZA
SMPL TIME : 2.0SEC
DATE : 01/01/13 12:15:00
[SELECT] [ ] [ ] [ ] [START]
EDIT **** *** *** 12:15:52
Press
[ ] [ ] [PUNCH] [ ] [ ]
[ ] [ ] [ ] [ CAN ] [ EXEC ]
Press
1.10.5
Outputting Waveform
Diagnosis Data
(Storage Type)
