0i/0i Mate - Model C Maintenance manual Page 281

Maintenance manual
B–64115EN/01
3. INPUT AND OUTPUT OF DATA
257
Writing a file
1 Press the EDIT switch on the machine operator’s panel.
2 Press function key
PROG
.
3 Press the rightmost soft key
(continuous menu key).
4 Press soft key
[CARD]. The screen shown below is displayed.
PROG (OPRT)DIR +
DIRECTORY (M–CARD)
No. FILE NAME SIZE DATE
O0034 N00045
0001 O1000 123456 01/07/10
0002 O1001 118458 01/07/30
0003 O0002 113250 01/07/30
0004 O2000 173456 01/07/31
0005 O2001 113444 01/07/31
0006 O3001 118483 01/08/02
0007 O3300 111406 01/08/05
0008 O3400 112420 01/07/31
0009 O3500 117460 01/07/31
~ ~
5 Press soft key [(OPRT)].
6 Press soft key
[PUNCH].
7 Enter a desired O number from the MDI panel, then set the program
number with soft key
[O SET].
When soft key
[EXEC] is pressed after the setting shown below has
been made, for example, the file is written under program number
O1230.
F NAME EXECSTOPO SET CAN
EDIT
*
* * * * * * * * * * * * *
15:40:21
PUNCH FILE NAME =
PROGRAM No. =1230
>
~ ~
8 In the same way as for O number setting, enter a desired file name
from the MDI panel, then set the file name with soft key
[F SET].
When soft key
[EXEC] is pressed after the setting shown below has
been made, for example, the file is written under program number
O1230 and file name ABCD12.
F NAME EXECSTOPO SET CAN
EDIT
*
* * * * * * * * * * * * *
15:40:21
PUNCH FILE NAME =ABCD12
PROGRAM No. =1230
>
~ ~
Procedure
DELETEPUNCHF SRH F READ N READ
