0i/0i Mate - Model C Maintenance manual Page 619

Maintenance manual
APPENDIX
B–64115EN/01
C. BOOT SYSTEM
595
1 Position the cursor to the name of the file to be deleted. Press the
[SELECT] soft key.
2 The system displays the following confirmation message :
*** MESSAGE ***
SAVE OK ? HIT YES OR NO.
3 To start saving, press the [YES] key. To cancel, press [NO].
*** MESSAGE ***
WRITING FLASH ROM FILE TO MEMORY CARD.
SAVE FILE NAME : PMC_RB.000
4 When saving terminates normally, the system displays the
following message. Press the [SELECT] key. The names of files
written to the memory card are listed. Check the file names by, for
example, making a note of the list.
*** MESSAGE ***
FILE SAVE COMPELETE. HIT SELECT KEY.
SAVE FILE NAME : PMC_RB.000
1 System files and user files on SYSTEM DATA SAVE screen
The SYSTEM DATA SAVE function provides a safeguard against free
copying of the system files.
User files, however, are not protected.
2 Names of saved files
Files saved from flash ROM to a memory card have the following
names :
Flash ROM File name in
Memory card
PMC–SB
PMC 0.5M
PMC 1.0M
PMC 1.5M
³
³
³
³
PMC_SB. XXX
PCD_0.5M.XXX
PCD_10M.XXX
PCD_15M.XXX
XXX corresponds to the file extension of MS–DOS format files. A
number from 000 to 031 is specified for XXX. For example, if the
PMC–RB file in flash ROM is saved to a memory card that does not yet
contain a file whose name begins with “PMC–RB”, the saved file is
named PMC–RB.000. If, however, that file is saved to a memory card that
already contains a file named PMC–RB.000, the saved file is named
PMC–RB.001. As files are added, the extension is incremented up to a
maximum of PMC–RB.031. Any no–longer used numbers in the
sequence of the extension numbers are used in as cending order. If two
or more files having identical names but different extension numbers are
normally saved to the memory card, check the file names displayed
subsequently.
D Operating procedure
D Others
