1) Select EDIT mode.
2) Press the
SYSTEM
key, then display the WAVE DIAGNOS. (MEMORY)
screen.
3) Open the write protect tab on the floppy disk or card.
4) Press the [W.MEM],
, [PUNCH], and [EXEC] soft keys, in this
order.
The waveform diagnosis data is output to a file named WAVE
DIAGNOS, to which the number of the last file is assigned.
If a file named WAVE DIAGNOS already exists in the floppy disk or on
the card, P/S alarm 86 is issued. A floppy disk or card can contain only
one file for waveform diagnosis data. If the existing WAVE DIAGNOS
file contains unnecessary waveform diagnosis data of servo alarm format,
delete that file before attempting to output new data. The procedure for
deleting a file is described later.
The directory in the cassette or card is displayed by means of the
following procedure:
1) Select EDIT mode.
2) Press the
PROG
function key to select the program screen.
3) Press the continuous menu key
, then press [FLOPPY].
4) Press page key
PAGE
.
The directory is displayed.
A file stored on a cassette or card is deleted by means of the following
procedure:
1) Select EDIT mode.
2) Press the
PROG
function key to select the program screen.
3) Set the write protect switch on the cassette or card to enable writing.
4) Press [FLOPPY].
5) Press [DELETE].
6) Enter the file number, then press [F SET].
7) Press [EXEC].
The file corresponding to the specified file number is deleted. The
number of each file subsequent to the deleted file is decremented by
one.
D Output to FANUC Floppy
Cassette or FA Card
D Directory display
D Deleting a file
