C. BOOT SYSTEM
597
1 Select “1. SRAM BACKUP.” The following confirmation message is
displayed. The backup file name may be displayed according to the
SRAM capacity.
2 Press [YES] to start backup.
*** MESSAGE ***
BACKUP SRAM DATA OK ? HIT YES OR NO.
3 If a backup file is already on the memory card, you will be prompted
to confirm whether to permit overwriting.
4 The name of the file being written to the memory card is displayed in
the FILE NAME: field.
SRAM SIZE : 1.0MB
FILE NAME : SRAM1_0A.FDB ³ MEMORY CARD
*** MESSAGE ***
SRAM DATA WRITING TO MEMORY CARD.
Name of the file being
saved
5 Upon terminating normally, the system displays the following
message. Press the [SELECT] soft key.
*** MESSAGE ***
SRAM BACKUP COMPLETE. HIT SELECT KEY.
1 Select “2. RESTORE SRAM.” The system displays the following
message. Press the [YES] key.
*** MESSAGE ***
RESTORE SRAM DATA OK ? HIT YES OR NO.
2 The system displays the following message during restoration.
*** MESSAGE ***
RESTORE SRAM DATA FROM MEMORY CARD.
3 Upon terminating normally, the system displays the following
message. Press the [SELECT] soft key.
*** MESSAGE ***
RESTORE COMPLETE. HIT SELECT KEY.
D Operating procedure
[Backing up data]
[Restoring the data]
