0i/0i Mate - Model C Maintenance manual Page 366

Maintenance manual

Page of 683

/ 683

4. INTERFACE BETWEEN CNC AND PMC

B–64115EN/01

342

Symbol M seriesT seriesAddress Signal name

ORARA

Orientationcompletion signal (serial spindle)

F045#7 f f

ORARB

Orientationcompletion signal (serial spindle)

F049#7 f f

ORCMA

Orientationcommand signal (serial spindle)

G070#6 f f

ORCMB

Orientationcommand signal (serial spindle)

G074#6 f f

OUT0 to OUT7 Software operator's panel general-purpose switch signal F072 f f

OVC Override cancel signal G006#4 f f

OVCE Override cancellationsignal (PMC axis control) G150#5 f f

OVRA

Analog override command signal (serial spindle)

G072#4 f f

OVRB

Analog override command signal (serial spindle)

G076#4 f f

PBATL Absolute position detector battery voltage low alarm signal F172#7 f f

PBATZ Absolute position detector battery voltage zero alarm signal F172#6 f f

PC1DTA

Signal indicatingthe status of the detected one

rotation

position coder signal (serial spindle)

F047#0 f f

PC1DTB

Signal indicatingthe status of the detected one rotation

position coder signal (serial spindle)

F051#0 f f

PC2SLC 2nd position coder selection signal G028#7 f f

PECK2 Small-diameter peck drilling in progress signal F066#5 – f

PN1,PN2,PN4,PN8,

PN16

Workpiece number search signal G009#0 to 4 f f

PORA2A

Signal for approximatespindle orientation with a position

coder (serial spindle)

F046#5 f f

PORA2B

Signal for approximatespindle orientation with a position

coder (serial spindle)

F050#5 f f

PRC Position record signal G040#6 f –

PRGDPL program screen display mode signal F053#1 f f

PRTSF Target parts count reached signal F062#7 f f

PSAR Spindle polygon speed arrival signal F063#2 f –

PSE1 Master axis not arrival signal F063#0 f –

PSE2 Polygon synchronous axis not arrival signal F063#1 f –

PSW01 to PSW16 Position switch signal F070#0 to F071#7 f f

PSYN Polygon synchronization under way signal F063#7 f –

R01I to R12I

Spindle motor speed command signal

G032#0 to G033#3 f f

R01I2 to R12I2

Spindle motor speed command signal

G034#0 to G035#3 f f

R01I3 to R12I3 G036#0 to G037#3 f f

R01O to R12O S12-bit code signal F036#0 to F037#3 f f

RCFNA

Output switch completion signal (serial spindle)

F046#3 f f

RCFNB

Output switch completion signal (serial spindle)

F050#3 f f

RCHA

Power line status check signal (serial spindle)

G071#7 f f

RCHB

Power line status check signal (serial spindle)

G075#7 f f

RCHHGA

High–output MCC status signal while a magnetic sensor

(serial spindle)

G072#7 f f

RCHHGB

High–output MCC status signal while a magnetic sensor

(serial spindle)

G076#7 f f

RCHPA

Output switch signal (serial spindle)

F046#2 f f

RCHPB

Output switch signal (serial spindle)

F050#2 f f
