FANUC Series 30i/ 31i/ 32i Live Tool Control With Servo Motor Specifications Additional Manual Page 18

Additional Manual
A-79805E
Title
Draw
No.
18/40
Sheet
FANUC Series 30i/ 31i/ 32i
Live Tool Control With Servo Motor
Edit
Apprv.Desig.
Date
Design
Descri
p
tion
Date
Oct.26.2004
1260 Amount of a shift per one rotation of a rotary axis
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Real axis
[Unit of data] degree
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] 0 or positive 9 digit of minimum unit of data (refer to the standard parameter
setting table (B))
(When the increment system is IS-B, 0.0 - +999999.999)
#7 #6 #5 #4 #3 #2 #1 #0
1408 IRC
[Input type] Parameter input
[Data type] Bit axis
# 3 IRC In live tool control with a servo motor, the unit of data for the maximum
cutting feedrate parameter (No.1430 (No.1432)) is
0: Not multiplied by 10.
1: Multiplied by 10.
If clamping at 360000 (deg/min), set 36000.0 in parameter No. 1430
(No. 1432).
1430 Maximum cutting feedrate for each axis
[Input type] Parameter input
[Data type] Realaxis
[Unit of data] mm/min, inch/min, degree/min (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 - +240000.0)
