FANUC Series 30i/ 31i/ 32i Live Tool Control With Servo Motor Specifications Additional Manual Page 37

Additional Manual
A-79805E
Title
Draw
No.
37/40
Sheet
FANUC Series 30i/ 31i/ 32i
Live Tool Control With Servo Motor
Edit
Apprv.Desig.
Date
Design
Descri
p
tion
Date
Oct.26.2004
Parameter
1430 Maximum cutting feedrate for each axis
[Input type] Parameter input
[Data type] Real axis
[Unit of data] mm/min, inch/min, degree/min (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 to +240000.0)
Specify the maximum cutting feedrate for each axis.
1432
Maximum cutting feedrate for all axes in the acceleration/deceleration before
interpolation
[Input type] Parameter input
[Data type] Real axis
[Unit of data] mm/min, inch/min, degree/min (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] Refer to the standard parameter setting table (C)
(When the increment system is IS-B, 0.0 to +240000.0)
Set a maximum cutting feedrate for each axis in the acceleration/
deceleration before interpolation mode such as AI contour control.
When the acceleration / deceleration before interpolation mode is not set,
the maximum cutting feedrate set in parameter No. 1430 is used.
#7 #6 #5 #4 #3 #2 #1 #0
11001 SRB
[Input type] Parameter input
[Data type] Bit axis
# 0 SRB As acceleration/deceleration for rigid tapping with servo motor cutting feed:
0: Linear acceleration/deceleration is used.
1: Bell-shaped acceleration/deceleration is used.
