FANUC Series 30i/ 31i/ 32i Live Tool Control With Servo Motor Specifications Additional Manual Page 25

Additional Manual
A-79805E
Title
Draw
No.
25/40
Sheet
FANUC Series 30i/ 31i/ 32i
Live Tool Control With Servo Motor
Edit
Apprv.Desig.
Date
Design
Descri
p
tion
Date
Oct.26.2004
3717 Motor number to each spindle
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Byte spindle
[Valid data range] 0 to Maximum number of controlled axes
Set a spindle amplifier number to be assigned to each spindle.
0：No spindle amplifier is connected.
1：Spindle motor connected to amplifier number 1 is used.
2：Spindle motor connected to amplifier number 2 is used.
to
n：Spindle motor connected to amplifier number n is used.
3718 Subscript for display of a serial spindle (main spindle) or analog spindle
[Input type] Parameter input
[Data type] Byte spindle
[Valid data range] 0 to 122
Set a subscript to be added to spindle speed display on a screen such as the
position display screen.
3719 Subscript for display of a serial spindle (sub-spindle)
[Input type] Parameter input
[Data type] Byte spindle
[Valid data range] 0 to 122
Set a subscript to be added to spindle speed display on a screen such as the
position display screen.
3741 Maximum spindle speed for gear 1
3742 Maximum spindle speed for gear 2
3743 Maximum spindle speed for gear 3
3744 Maximum spindle speed for gear 4
[Input type] parameter input
[Data type] 2-word spindle
[Unit of data] min-1
[Valid data range] 0 to 99999999
Set the maximum spindle speed corresponding to each gear.
