FANUC Series 30i/ 31i/ 32i
Live Tool Control With Servo Motor
Edit
Apprv.Desig.
Date
Design
Descri
tion
Date
Oct.26.2004
#7 #6 #5 #4 #3 #2 #1 #0
3703 MPP MPM 2P2
[Input type] Parameter input
[Data type] Bit
NOTE
When this parameter is set, the power must be turned
off
before operation is continued.
# 0 2P2 When a multi-path system is used, inter-path spindle control allows:
0: Configuration where the spindle that belongs to one path only is shared
between path 1 and path 2.
1: Configuration where the spindles that belong to path 1 and 2 are shared
between the two paths.
When the spindle that belongs to an arbitrary path is shared between
arbitrary paths,
set bit 2 (MPM) of parameter No. 3703. (The meanings of signals used vary,
so that
ladder program modifications need to be made.)
# 2 MPM When a multi-path system is used, the configuration allowed by interpath
spindle control:
0: Follows the setting of bit 0 (2P2) of parameter No. 3703.
1: Allows the sharing of the spindle that belongs to a path between
arbitrary paths.
# 3 MPP In multi-spindle control, a spindle selection using a programmed
command instead of using the signals (SWS1 to SWS4<G027#0 to
#2,G026#3>) is:
0: Not made.
1: Made.
NOTE
When this parameter is set to 1, set parameter
No.3781 at the same time.
