  2. FANUC Series 30i/ 31i/ 32i Live Tool Control With Servo Motor Specifications

FANUC Series 30i/ 31i/ 32i Live Tool Control With Servo Motor Specifications Additional Manual Page 29

Additional Manual
A-79805E
Title
Draw
No.
29/40
Sheet
FANUC Series 30i/ 31i/ 32i
Live Tool Control With Servo Motor
Edit
Apprv.Desig.
Date
Design
Descri
p
tion
Date
Oct.26.2004
11015 Maximum motor speed
[Input type] Parameter input
[Data type] 2-word axis
[Unit of data] min
-1
[Valid data range] 0 to 99999999
An actual maximum speed of the motor becomes a speed that the feeding
gear is effective in parameter No.11015.
11020 Acceleration/deceleration switching speed (S
0
) for each axis
11021 Acceleration/deceleration switching speed (S
1
) for each axis
[Input type] Parameter input
[Data type] 2-word axis
[Unit of data] min
-1
[Valid data range] 0 to 99999999
Set the acceleration/deceleration switching points S
0
and S
1
for each axis.
11030 Individual acceleration / deceleration 1 (Leg 1)
11031 Individual acceleration / deceleration 2 (Leg 2)
11032 Individual acceleration / deceleration 3 (Leg 3)
[Input type] Parameter input
[Data type] 2-word axis
[Unit of data] min
-1
/s
[Valid data range] 0 to 99999999
Set the acceleration/deceleration of Leg 1 (0 to S
0
), Leg 2 (S
0
to S
1
), and Leg
3 (S
1
to Maximum speed) for each axis.
