FANUC Series 30i/ 31i/ 32i Live Tool Control With Servo Motor Specifications Additional Manual Page 19

Additional Manual
A-79805E
Title
Draw
No.
19/40
Sheet
FANUC Series 30i/ 31i/ 32i
Live Tool Control With Servo Motor
Edit
Apprv.Desig.
Date
Design
Descri
p
tion
Date
Oct.26.2004
1820 Command multiplier for each axis (CMR)
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Byte axis
[Valid data range] See below.
Set a command multiplier indicating the ratio of the least command
increment to the detection unit for each axis.
Least command increment = detection unit × command multiplier
Relationship between the increment sytem and least command increment.
(1) T series
Least input increment
Least command
increment
0.001mm (diameter specification) 0.0005mmMillimeter
input
0.001mm (radius specification) 0.001mm
0.0001inch (diameter specification) 0.0005mm
Millimeter
machine
Inch input
0.0001inch (radius specification) 0.001mm
0.001mm (diameter specification) 0.00005inchMillimeter
input
0.001mm (radius specification) 0.0001inch
0.0001inch (diameter specification) 0.00005inch
Inch
machine
Inch input
0.0001inch (radius specification) 0.0001inch
IS-B
Rotation axis 0.001deg 0.001deg
Least input increment
Least command
increment
0.0001mm (diameter specification) 0.00005mmMillimeter
input
0.0001mm (radius specification) 0.0001mm
0.00001inch (diameter specification) 0.00005mm
Millimeter
machine
Inch input
0.00001inch (radius specification) 0.0001mm
0.0001mm (diameter specification) 0.000005inchMillimeter
input
0.0001mm (radius specification) 0.00001inch
0.00001inch (diameter specification) 0.000005inch
Inch
machine
Inch input
0.00001inch (radius specification) 0.00001inch
IS-C
Rotation axis 0.0001deg 0.0001deg
