FANUC Series 30i/ 31i/ 32i Live Tool Control With Servo Motor Specifications Additional Manual Page 40

Additional Manual
A-79805E
Title
Draw
No.
40/40
Sheet
FANUC Series 30i/ 31i/ 32i
Live Tool Control With Servo Motor
Edit
Apprv.Desig.
Date
Design
Descri
p
tion
Date
Oct.26.2004
11065
Time constant for acceleration/deceleration deceleration after cutting feed
interpolation in rigid tapping extraction (first gear)
11066
Time constant for acceleration/deceleration deceleration after cutting feed
interpolation in rigid tapping extraction (second gear)
11067
Time constant for acceleration/deceleration deceleration after cutting feed
interpolation in rigid tapping extraction (third gear)
Time constant for acceleration/deceleration deceleration after cutting feed
interpolation in rigid tapping extraction (fourth gear)
11068
[Input type] Parameter input
[Data type] Word axis
[Unit of data] msec
[Valid data range] 0 to 4000
When bit 2 (TDR) of parameter No. 5201 is set to 1, time constants
for extraction of rigid tapping with servo motor can be set in these
parameters (Nos. 11065 to 11068).
Set these parameters with a live tool axis in rigid tapping.
