Set by the following expression. fc : Cut-off frequency [Hz], τ : Sampling time [sec]
(Setting value) = 4096 × exp(-2µ×fc×τ)
(Example 1) Case of normal axis (τ = 1msec) and fc = 100 [Hz]
No.2067 = 4096 × exp(-2π×100×0.001) = 2185
(Example 2) Case of high gain axis (τ = 0.5msec) and fc = 100 [Hz]
No.2067 = 4096 × exp(-2π×100×0.0005) = 2992
(Example 3) Case of high speed axis (αL6, αL9, τ = 125µsec) and fc = 100 [Hz]
No.2067 = 4096 × exp(-2π×100×0.000125) = 3787
Normal axis
(τ = 1ms)
High Gain axis
(τ = 0.5ms)
No.74 or No.75
(τ = 125µs)
20Hz 3612 3847 4032
40Hz 3186 3612 3969
60Hz 2810 3392 3907
80Hz 2478 3186 3847
100Hz 2185 2992 3787
120Hz 1927 2810 3728
140Hz 1700 2638 3669
160Hz 1499 2478 3612
180Hz 1322 2327 3556
200Hz 1166 2185 3501
250Hz 851 1868 3366
300Hz 622 1596 3236
Standard : 0
You should not change this parameter from standard setting value.
(Note) Motor type No. 75 applied to αL6 (Motor No.75) or αL9 (Motor No.74) have the special value
designed to optimize with HRV control, so that the torque increase than without HRV.
Data range : from 250 to 992 (Hz)
Data range : 0, 20, 30, 40 (Hz)
* HRV filter is available with 90Bx/04 or later
2110
MSGTCM Magnetic saturation compensation coefficient 9083/A
2067
FILTER Tcmd filter coefficient
2113
Vibration suppression filter central frequency (Hz) 90A3/A
2177
Vibration suppression filter band width (Hz) 90A3/A
