  2. FANUC AC Servo Software 90A3 / 90A7 Series, 90B3 / 90B7 Series Learning Function, Operator

FANUC AC Servo Software 90A3 / 90A7 Series, 90B3 / 90B7 Series Learning Function, Operator Additional Manual Page 47

Additional Manual
Title 90A3 / 90A7 / 90B3 / 90B7
Learning Control Operator’s Manual
03 ’01.01.13 K.Maeda 3
rd
. updated Draw No.
02 '03.01.06 K.Maeda 2
nd
. updated
A - 63639E - 070
01 ’00.09.20 K.Maeda Newly designed Sheet 047
Edit Date Design Description / 081
Fixed size
41kW
Examples
(1) Correspondence with processing program and Work
Learning memory

Profile i


Profile j
Profile i

Profile i


Profile j
File on com
p
ute
r
In case of partial deal method, each file size is
small, but you need to manage Total profile
number and Profile number by yourself.
Profile j
O0001 ;
G10 L50 ;
N2264 P (Axis) R (Total profile number) ;
G11 ;

G10 L50 ;
N2233 P (Axis) R (Profile number
i) ;
N2242 P (Axis) R (Learning count) ;
N2243 P (Axis) R (Learning period) ;
 (each step) 
G11 ;
G05 (Profile
i command) ;

G10 L50 ;
N2233 P (Axis) R (Profile number
j) ;
N2242 P (Axis) R (Learning count) ;
N2243 P (Axis) R (Learning period) ;
 (each step) 
G11 ;
G05 (Profile
j command) ;

Grinding
C axis
Profile i Profile j
CAM work
X axis
Total profile number
A
bove case consists of six profiles in one
camshaft, supposing all have different
profile each other.
(Max. 16 profiles are available )
Previous page
Next page
