FANUC AC Servo Software 90A3 / 90A7 Series, 90B3 / 90B7 Series Learning Function, Operator Additional Manual Page 76

Additional Manual
Title 90A3 / 90A7 / 90B3 / 90B7
Learning Control Operator’s Manual
03 ’05.01.13 K.Maeda 3
rd
. updated Draw No.
02 '03.01.06 K.Maeda 2
nd
. updated
A - 63639E - 070
01 ‘00.09.20 K.Maeda Newly designed Sheet 076
Edit Date Design Description / 081
Appendix 7. Notes on using SD.EXE
In the servo software for Learning control, the using way of SD.EXE is different from in standard servo
software. We describe the difference and cautions. Regarding the details of SD.EXE, refer to the manual
attached SD.EXE. Refer to "4.18 SERVO CHECK BOARD OPERATING PROCEDURE" in B-65270E.
7.1 Dip-switch and data contents
You can select the data content by Dip-switch (4 bits) on Digital check-board.
Dip-switch
(
B3
,
B2
,
B1
,
B0
)
LED
Check board
A
Standard series Learning series
90A3
Learning series
90A7
Learning series
90B3
,
90B7
0
,
0
,
0
,
0
1 0
Vcmd
(
L-axis
)
Error
(
L-axis
)
Error
(
L-axis
)
Error
(
L-axis
)
0
,
0
,
0
,
1
1 1
Tcmd
(
L-axis
)
Tcmd
(
L-axis
)
Tcmd
(
L-axis
)
Tcmd
(
L-axis
)
0
,
0
,
1
,
0
2 0
Vcmd
(
M-axis
)
Mcmd
(
L-axis
)
Error
(
M-axis
)
Vcmd
(
M-axis
)
0
,
0
,
1
,
1
2 1
Tcmd
(
M-axis
)
Tcmd
(
M-axis
)
Tcmd
(
M-axis
)
0
,
1
,
0
,
0
1 2
TSA
(
L-axis
)
TSA
(
L-axis
)
TSA
(
L-axis
)
TSA
(
L-axis
)
0
,
1
,
0
,
1
2 2
TSA
(
M-axis
)
TSA
(
M-axis
)
TS
A
(
M-axis
)
1
,
0
,
0
,
0
1 4
Pos.
(
L-axis
)
Pos.
(
L-axis
)
Pos.
(
L-axis
)
1
,
0
,
0
,
1
2 4
Pos.
(
M-axis
)
Pos.
(
M-axis
)
Pos.
(
M-axis
)
1
,
0
,
1
,
0
1 5
Pos.
(
L-axis
)
∗
1Pos.
(
L-axis
)
∗1 Pos.
(
L-axis
)
∗
1
1
,
0
,
1
,
1
2 5
Pos.
(
M-axis
)
∗1 Pos.
(
M-axis
)
∗
1
1) Regarding the display unit for Error and Mcmd, you should select “POS” in SYSTEM setting screen of
SD.EXE, and set the following.
Error Display unit (mm) : 1pulse=Least detective unit (mm) / 32 (Case of N2012#5,#4=0,0)
Recommend → : 1pulse=Least detective unit (mm) / 2 (Case of N2012#5,#4=0,1)
Mcmd Display unit (mm/sec) : 1pulse=Least detective unit (mm) / 32 / Velocity loop period (sec)
2) If you set non-zero value for No.2115, TSA is not output. (90A3 or 90A7)
3) When you set 4788 (L) or 6836 (M) for No.2115, the marked “∗1” is outputted.
4) Case that you observe "Mcmd", you should use Arbitrary data serial output function.
7-2. Limit of measurement
The speed which it is possible to measure is below 1024 Least detective unit per Velocity loop period.
(Example) When Velocity loop 1ms and 0.1µm Least detective unit, the speed limit is 6m/min.
You can expand the speed limit.
No.2115 Limit of measurement ∗2 Display unit ∗3
4787(L), 6835(M) 2048 2 times of Least detective unit
4786(L), 6834(M) 4096 4 times of Least detective unit
4785(L), 6833(M) 8192 8 times of Least detective unit
4784(L), 6832(M) 16384 16 times of Least detective unit
∗2 Least detective unit per Velocity loop period
∗3 “POS” in SYSTEM setting screen of SD.EXE
In case that the speed gets over the above limit, there is a possibility of interpolation by “CTRL-j” in
SD.EXE after gathering the data.
