Title 90A3 / 90A7 / 90B3 / 90B7

Learning Control Operator’s Manual

03 ’05.01.13 K.Maeda 3

. updated Draw No.

02 '03.01.06 K.Maeda 2

. updated

A - 63639E - 070

01 ‘00.09.20 K.Maeda Newly designed Sheet 075

Edit Date Design Description / 081

Appendix 6. Checking Position Error by Check-board

1. Setting

Learning axis can put out the position error to Check-board. The output signal range is ±5V. Conversion

value is variable by both No.2012#5 and #4 as follows.

Parameter B5 B4 Magnification Pulses / 5V

Least detect 0.1µm

0.1µm / V

Least detect 0.003deg

deg / V

0 0 1 64 1.28 0.0384

0 1 16 1024 20.48 0.6144

1 0 256 16384 327.68 9.8304

No.2012

1 1 4096 262144 5242.88 157.2864

2. Output channel

The channel of output signal is as follows. Vcmd signal is not put out at Learning axis.

• Normal axis

• Learning axis (No.2008#5 = 1) or High-speed axis (No.2005#4 = 1)

• Learning axis (90A7, 90B3, 90B7 series) ** CH3 : Error (M) in 90A7 only

(Note) When No.2007#0 = 1, the marked “∗” shows Vcmd + Feed-forward.

(Note) To use check-board, the servo wave checking adapter (A02B-0120-C211) needs.

In i -series, you must use the other adapter (A02B-0236-K822).

3. The other signal conversion

In the High-speed axis, the output conversion values are different from normal axis as follows.

Output signal Normal axis High-speed axis

Vcmd 0.1875 (min

-1

/ V)

Tcmd 9 ∗ Imax / 40 *1 (A

/ V) Same left

Mcmd 2.458 (m/min / V) *2

Vcmd+F.F. 0.1875 (min

-1

/ V)

TSA 750 (min

-1

/ V) Same left

(Note 1) Imax shows the max. current value of servo amplifier.

(Note 2) The conversion value of Mcmd is used when Least detective unit is 0.1µm, Velocity loop is 1msec.

If Velocity loop is 0.5msec, that value is 4.916 (m/min / V).

CH6

(

)

CH5

(

)

CH4

Tcmd

(

)

CH3

Vcmd

(

)

CH2

Tcmd

(

)

CH1

Vcmd

(

)

CH6 CH5

(

)

CH4

∗

CH3

Mcmd

(

)

CH2

Tcmd

(

)

CH1

Error

(

)

CH6

TSA

(

)

CH5

(

)

CH4

Tcmd

(

)

CH3 **

Vcmd

(

)

CH2

Tcmd

(

)

CH1

Error

(

)
