FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
103
12.4 Writing a tool management data
[Description]
This function writes a tool data according to specified magazine and pot number. If the pot has no tool (if
tool management data number is not allocated), error 9 is output.
- Data length is changed according to the option ”Additional customized data on tool management
function”. If the option exists, data length is 140. If not, data length is 76.
[Input data structure]
0 (Function code)
332
2 (Completion code)
-
4
(Data length)
76,140
6
(Data number)
Magazine number
8
(Data attribute)
-
10
(Data number2)
Pot number
12
(Detail completion code)
-
14
Tool type number (4byte)
18
Tool life counter (4byte)
22
Maximum of tool life (4byte)
26
Previous notice tool life (4byte)
30
State of Tool life (1byte)
31
Customizing data 0 (1byte)
32
Tool information (2byte)
34
Cutter compensation number H (2byte)
36
Tool length compensation number D (2byte)
38
Spindle speed S (4byte)
42 Feedrate F (4byte)
Machining and
Lathe
(
Com
p
ound
)
s
y
ste
m
