FS16i/18i/21i - TB/MA/MB Additional Manual Page 29

Additional Manual
FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
29
READ/WRITE of tool management data
table and magazine management table
As for the tool management data table and the magazine management table,
reading/writing is possible by using CNC/PMC data window library
(FOCAS1). So, by using OPEN CNC, it is easy to make original tool
management system which manages all the usable tools even if it is not
registerd with CNC.
The tool management data table and the magazine management table can be
read/write by the PMC window, too.
Tool management data about the tool of spindle position which was
commanded by M06 and the tool which is being selected by T code can be
read by the Custom Macro.
The user can change the tool management data from the tool management
function screen on the CNC with MDI. It is possible to register/alter/delete
the tool management data by part program (G10) . And, it is possible to
input and output from ALL I/O screen / the tool management function
screen to an external device.
