FS16i/18i/21i - TB/MA/MB Additional Manual Page 25

Additional Manual
FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
25
Search sequence of tool
Tool kind number (T) instructed by the program is retrieved and the tool is
retrieved while sequentially checking the content of the registration data
from the first of the tool control data numbers. The search means in NC in
that case is as follows.
N
o
(
invalid
)
Is the tool management data valid ?
(Is Bit 0 RGS of tool information set as “1” ?)
Yes
(
valid
)
Yes
(
editin
g)
Editing tool ?
(tool management data number blink ?)
N
o
(
no editin
g)
N
o
(
not same
)
Is tool type number (T) the same number ?
Yes
(
same
)
o
not re
istered
Registered in the magazine ?
(magazine number is not “0” ?)
Yes
(
re
g
istered
)
N
o
(
not tar
g
et
)
Search target magazine ?
(PRM No.13003#0 to #3 is set to “0” ?)
Yes
(
tar
g
et
)
Yes
(
re
g
istered
)
Registered in spindle or wait position
in other path ?
o
not re
istered
Yes
(
not mana
g
ed
)
N
o
(
not tar
g
et
)
Search target ?
(Is tool information bit 4 SEN set to “1” ?)
Yes
(
tar
g
et
)
Search end
N
o
(
mana
g
ed
)
Is tool life state "tool not managed" ?
