FS16i/18i/21i - TB/MA/MB Additional Manual Page 81

Additional Manual
FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
81
Tool management data changing signal TLSG10 <F315#2>
[Classification] Output signal
[Function] Reports that the tool management data, magazine management data
and string data is being changed by the command of G10 L75/L76/L77.
[Output condition] The signal is set to "1" when:
•
••
• The tool management data or the magazine management data is being
changed by the command of G10 L75/L76/L77.
The signal is set to "0" when:
•
••
• The data changing mode of the tool management data and magazine
management data is finished by the command of G11 or the RESET
button.
NOTE
When the tool management data changing signal
TLMG10 is set to “1”, please take care not to rewrite
the tool management data by the PMC window and
FOCAS1
Tool management data outputing signal TLMOT <F315#4>
[Classification] Output signal
[Function] Reports that the tool management data, magazine management data
and string data is being output.
[Output condition] The signal is set to "1" when:
•
••
• The tool management data and magazine management data punch
process starts.
The signal is set to "0" when:
•
••
• The punch process is finished.
NOTE
When the tool management data outputing signal
TLMOT is set to “1”, please take care not to rewrite
the tool management data by the PMC window and
FOCAS1
Tool management data editing signal TLMEM <F315#7>
[Classification] Output signal
[Function] Reports that CNC is in the tool management data edit mode.
[Output condition] The signal is set to “1” when:
The tool management data edit mode starts on the tool management
screen.
The signal is set to “0” when:
The tool management data edit mode ends on the tool management
screen.
