FS16i/18i/21i - TB/MA/MB Additional Manual Page 90

Additional Manual
FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
90
13227 Data number of second magazine
[Data type] Word
[Valid data range] 1 to 64 (additional option : 1 to 240, 1 to 1000)
Sets the range of data number used in second magazine.
13228 First pot number of the second magazine
[Data type] Word
[Valid data range] 1 to 9999
Sets the first pot number of the second magazine. Pot number is allotted
to each data number with one adding to the value of the parameter.
13232 Data number of third magazine
[Data type] Word
[Valid data range] 1 to 64 (additional option : 1 to 240, 1 to 1000)
Sets the range of data number used in third magazine.
13233 First pot number of the third magazine
[Data type] Word
[valid data range] 1 to 9999
Sets the first pot number of the third magazine. Pot number is allotted
to each data number with one adding to the value of the parameter.
13237 Data number of fourth magazine
[Data type] Word
[Valid data range] 1 to 64 (additional option : 1 to 240, 1 to 1000)
Sets the range of data number used in fourth magazine.
13238 First pot number of the fourth magazine
[Data type] Word
[Valid data range] 1 to 9999
Sets the first pot number of the fourth magazine. Pot number is allotted
to each data number with one adding to the value of the parameter.
