FS16i/18i/21i - TB/MA/MB Additional Manual Page 86

Additional Manual
FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
86
#7 #6 #5 #4 #3 #2 #1 #0
13200 NFD NAM T0O TP2 ETE TRT THN TCF
[Data type] Bit
TCF When a T code of the tool management function is commanded:
0 : Output the magazine number and the pot number.
1 : Output the commanded T code.
THN The display of NX.T,HD.T in tool management functionn is
0 : Tool type number at the spindle position and the wait position.
1 : Instruction value from the PMC window.
TRT The previous notice life for the previous notice of tool life attainment
signal is
0 : The previous notice life of the last tool.
1 : The sum of the previous notice life of the same tool type.
ETE The previous notice of tool life attainment signal is output by
0 : each tool type number.
1 : each tool.
TP2 The punch out sytle of magazine management data is
0 : new registration type. ( G10 L76 P1; )
1 : modification type. ( G10 L76 P2; )
T0O If the T0 command was specified,
0 : the search is executed as the tool variable number is 0.
1 : the magazine and pot number is output as 0.
NOTE
- TRT is only enable in case the parameter
ETE(No.13200#3) is set to 0.
NAM When an effective tool with the remainder life is not found in the
instruction in T code
1: The TMFNFD<F315#6> is output instead of P/S alarm.
0: P/S alarm is generated.
NFD When an effective tool that there is the remainder life in the magazine is
not found in the instruction in T code
1: The spindle position/the wait position is not searched.
0: The spindle position/the wait position is searched.
